Service Manual2006 Captiva TRANSMISSION / TRANSAXLE / TRANSFER CASE (FIVE-SPEED MANUAL TRANSAXLE : D33)

SECTION 5B4

TRANSMISSION / TRANSAXLE / TRANSFER CASE (FIVE-SPEED MANUAL TRANSAXLE : D33)

FIVE-SPEED M/T(D33) - MANUAL TRANSAXLE (561)

NO.	OPERATION DESCRIPTION	OPERATION CODE	MODEL
NO.	OPERATION DESCRIPTION	OPERATION CODE	C	.
1	. TRANSAXLE ASSEMBLY - REPLACE	5610100	3.7	.
	INC : Replace concentric slave cylinder necessary	.	.	.
	A - With Transfer Case	561010A	4.3	.
	. TRANSAXLE ASSEMBLY - OVERHAUL	5610300	7.6	.
	A - With Transfer Case	561030A	8.2	.
	. TRANSAXLE OIL - REPLACE	5610500	0.4	.

C : C-100

FIVE-SPEED M/T(D33) - TRANSAXLE GEAR (563)

NO.	OPERATION DESCRIPTION	OPERATION CODE	MODEL
NO.	OPERATION DESCRIPTION	OPERATION CODE	C	.
1	. GEAR, OUTPUT - 5TH SPEED (DRIVEN) - REPLACE	5630100	5.9	.
1	A - With Transfer Case	563010A	6.5	.
2	. GEAR, INPUT - 5TH SPEED (DRIVING) - REPLACE	5630200	5.8	.
2	A - With Transfer Case	563020A	6.4	.
3	. GEAR, OUTPUT - 4TH SPEED (DRIVEN)- REPLACE	5630300	5.7	.
3	A - With Transfer Case	563030A	6.3	.
4	. GEAR, INPUT - 4TH SPEED (DRIVING) - REPLACE	5630400	5.6	.
4	A - With Transfer Case	563040A	6.2	.
5	. GEAR, OUTPUT - 3TH SPEED (DRIVEN)- REPLACE	5630500	5.8	.
5	A - With Transfer Case	563050A	6.4	.
6	. GEAR, INPUT - 3TH SPEED (DRIVING) - REPLACE	5630600	5.7	.
6	A - With Transfer Case	563060A	6.3	.
7	. GEAR, INTERMEDIATE-2TH SPEED (DRIVING) - REPLACE	5630700	5.7	.
7	A - With Transfer Case	563070A	6.3	.
8	. GEAR, INTERMEDIATE-1TH SPEED (DRIVING) - REPLACE	5630900	5.7	.
8	A - With Transfer Case	563090A	6.3	.
9	. SHAFT, TRANSAXLE INPUT - REPLACE	5631000	5.9	.
9	A - With Transfer Case	563100A	6.5	.
10	. SHAFT, TRANSAXLE OUTPUT - REPLACE	5631100	6.1	.
10	A - With Transfer Case	563110A	6.7	.
11	. GEAR, REVERSE (DRIVEN ) - REPLACE	5631200	6.0	.
11	A - With Transfer Case	563120A	6.6	.

C : C-100

FIVE-SPEED M/T(D33) - TRANSAXLE GEAR (563)

NO.	OPERATION DESCRIPTION	OPERATION CODE	MODEL
NO.	OPERATION DESCRIPTION	OPERATION CODE	C	.
12	. SYNCHRONIZERS ( 5TH / REVERSE ) - REPLACE	5631300	5.9	.
12	A - With Transfer Case	563130A	6.5	.
13	. GEAR, INTERMEDIATE - REPLACE	5631400	5.7	.
13	A - With Transfer Case	563140A	6.3	.
14	. SYNCHRONIZERS (3RD-4TH) - REPLACE	5631500	5.7	.
14	A - With Transfer Case	563150A	6.3	.
15	. SYNCHRONIZERS (1ST-2ND) - REPLACE	5631700	5.7	.
15	A - With Transfer Case	563170A	6.3	.

C : C-100

FIVE-SPEED M/T(D33) - BEARING PLATE (565)

NO.	OPERATION DESCRIPTION	OPERATION CODE	MODEL
NO.	OPERATION DESCRIPTION	OPERATION CODE	C	.
1	. REAR COVER, TRANSAXLE - REPLACE	5650100	0.6	.
2	. TRANSMISSION FLUID COLLECTOR PIPE - REPLACE	5650200	0.6	.
3	. BEARING, BALL GROOVE - REPLACE	5650400	4.8	.
3	A - With Transfer Case	565040A	5.4	.
4	. OIL DRAIN CHAINNEL - REPLACE	5650600	4.5	.
4	A - With Transfer Case	565060A	5.1	.
5	. MAGNET, T/A HOUSHING - REPLACE	5650800	4.5	.
5	A - With Transfer Case	565080A	5.1	.
6	. RAIL, IDLE SHIFT - REPLACE	5651000	4.7	.
6	A - With Transfer Case	565100A	5.3	.

C : C-100

FIVE-SPEED M/T(D33) - GEAR SHIFT COVER & FORK (566)

NO.	OPERATION DESCRIPTION	OPERATION CODE	MODEL
NO.	OPERATION DESCRIPTION	OPERATION CODE	C	.
1	. SHIFT SHAFT ASSEMBLY - REPLACE	5660200	4.5	.
1	A - With Transfer Case	566020A	5.1	.
2	. CONTROL LEVER, SELECT - REPLACE	5660400	0.5	.
3	. TRANSAXLE CASE - REPLACE	5661100	5.0	.
3	A - With Transfer Case	566110A	5.6	.
4	. CLUTCH CASE - REPLACE	5661300	4.5	.
4	A - With Transfer Case	566130A	5.1	.

C : C-100

FIVE-SPEED M/T(D33) - DIFFERENTIAL GEAR (567)

NO.	OPERATION DESCRIPTION	OPERATION CODE	MODEL
NO.	OPERATION DESCRIPTION	OPERATION CODE	C	.
1	. DIFFERENTIAL ASSEMBLY - REPLACE	5670100	4.7	.
1	A - With Transfer Case	567010A	5.3	.
2	. SEALS, AXLE (TRANSAXLE) - REPLACE (RIGHT)	.	.	.
	Right	5671300	1.0	.
	Left	5671400	1.0	.
	Both	5671500	1.6	.
3	. DIFFERENTIAL RACE AND/OR SHIM - REPLACE	5671700	5.0	.
3	A - With Transfer Case	567170A	5.6	.
4	. DRAIN PLUG, TRANSAXLE FLUID - REPLACE	5671800	0.2	.

C : C-100

FIVE-SPEED M/T(D33) - SHIFT CONTROL (569)

NO.	OPERATION DESCRIPTION	OPERATION CODE	MODEL
NO.	OPERATION DESCRIPTION	OPERATION CODE	C	.
1	. LEVER, GEARSHIFT CONTROL ASSEMBLY - REPLACE	5690500	0.9	.
2	. CABLE LOCK PIN, CONTROL ASSEMBLY - REPLACE	5690600	0.3	.
3	. CONTROL ASSEMBLY, FLOOR MOUNTED GEARSHIFT - REPLACE	5690900	1.0	.
3	INC : Adjust Linkage	.	.	.
